ALLEGION SCHLAGE F SERIES MERANO
Application Residential
Description
Schlage F-Series residential handlesets are forged of solid brass and are ergonomically designed with solid handles for a comfortable grip. Designed to complement the F-Series knobs and levers, handlesets enhance the appearance of any front door entrance. With a range of designs and finishes, the Schlage range of F-Series handlesets can provide you with a design to suit your home. F-Series handlesets are fitted with B300 Maximum Security Deadbolts, which have a full 25mm-throw deadbolt and Schlage’s patented wood frame reinforcer for added security. Schlage’s Ultima Lifetime Finish & Lifetime Mechanical Warranties are standard on all F-Series handlesets when used in residential applications
Warranty
Lifetime mechanical, Lifetime finish on SNP and PB. 10 years finish on AD, AP and SCP
General Specifications
Door thickness | 41mm to 51mm |
Fixing | Concealed |
Material | Solid forged brass |
Handing | Non-handed |
Backset | 60mm/70mm adjustable |
Cylinder | Brass 6 Pin Tumbler Schlage C5 keyway standard |
Latchbolt | Brass, 13mm |
